DOUBLE DECK SYSTEM- MS 450

Doppelstock-MS-450-CAD

INFORMATIONS

Double Deck System – MS 450

Modular beam system Main steel beam IPE 450 profile / secondary steel beam IPE 270 profile
traffic load 3.5 kN/m², increase to 5.0 kN/m² possible
supports / tube Ø = 245 mm, 10 mm thick / base plate Ø = 800 mm, 40 mm thick
Standard installation heights 16 – 21 pitches, installation heights 2848 – 3738 mm, other heights possible
Roof construction Heights 2848 – 3738 mm
Soffit in coated chipboard of your choice
No dowelling on the hall floor
Openings for supply lines
roll-off safety by aluminium Z-profile or flat material
Structures with visual requirements are painted in Feyco 13702 dark grey

PLANNING

Our team realises your individual stand design for steel platforms or special constructions according to your specifications at the latest AutoCAD workstations, taking into account the respective technical measurement guidelines and static feasibility.

Static calculations are made in cooperation with our engineering office and submitted by us to the respective event service.

PRECONFIGURED STEEL PLATFORMS

GALLERY

katalog

CATALOGUE

Ask for our detailed planning and architect folder.
